| Motherboard Specification | |
| Chipset | H510 |
| Form Factor | M-ATX |
| Audio | Realtek® ALC897 Codec |
| Socket | LGA 1200 |
| Memory Specification | |
| Memory Type | DDR4 |
| Max Number of Channels | Dual |
| Memory Capacity | 64 |
| Connectors | |
| LAN | 1x Realtek® RTL8111 Gigabit LAN controller |
| USB | Intel H310 Chipset 4 x USB 3.1 Gen1 (SuperSpeed USB) ports (2 Type-A ports on the back panel, 2 ports available through the internal USB connectors) 6 x USB 2.0 (High-speed USB) ports (4 Type-A ports on the back panel, 2 ports available through the internal USB connectors) |
| TPM (Trusted Platform Module ) | 1 |
| VGA | 1 |
| DVI-D | 11 |
| Display Port | 1 |
| Ports & Slots | |
| Ports | USB 3.2 Ports (Front) 2(Gen 1, Type A) USB 3.2 Ports (Rear) 2(Gen 1, Type A) USB 2.0 Ports (Front) 2 USB 2.0 Ports (Rear) 4 |
| Internal I/O Ports | 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 4 x SATA 6Gb/s connectors 1 x USB 3.1 Gen1 connector (supports additional 2 USB 3.1 Gen1 ports) 1 x USB 2.0 connector (supports additional 2 USB 2.0 ports) 1 x 4-pin CPU fan connector 1 x 4-pin system fan connector 1 x Front panel audio connector 1 x Serial port connector 2 x Front panel connectors 1 x Chassis Intrusion connector 1 x Clear CMOS jumper |
| PCI-E | PCI-EX16 1 PCI-EX1 2 PCI-E GEN Gen 4 SATA III 4 |
| Physical Specification | |
| Dimensions (W x D x H) | 236 cm x 190 cm |
| Weight | 0.900000 |
| Warranty Information | |
| Warranty | 03 year |
The MSI PRO H510M-B DDR5 ATX Motherboard, is a powerful and feature-packed motherboard designed to elevate your computing experience. With its Intel H470 chipset and support for 10th Gen Intel Core and Pentium Gold/Celeron processors, this motherboard delivers exceptional performance and reliability for a wide range of applications. Memory-wise, the motherboard offers two DDR4 slots with a maximum capacity of 64GB. It supports memory speeds of 2933/2666/2400/2133 MHz, featuring 1R 2133/2666/2933 MHz support for Intel Core i9/Core i7 CPUs and 1R 2133/2666 MHz support for Intel Core i5/Core i3/Pentium Gold and Celeron CPUs. The motherboard also supports dual-channel mode, non-ECC un-buffered memory, and Intel Extreme Memory Profile (XMP) for optimized memory performance. In terms of graphics, the MSI PRO H510M-B features 1x HDMI™ and 1x VGA ports. The HDMI port supports HDMI™ 1.4 with a maximum resolution of 4K at 30Hz (available only on processors with integrated graphics).
