Specification
| Basic Information | ||
| Base Frequency | 2.50 GHz | |
| Maximum Turbo Frequency | 4.90 GHz | |
| Cache | 16MB | |
| Cores | 8 | |
| Threads | 16 | |
| Default TDP | 65 W | |
| Memory Specifications | ||
| Maximum Size | 128 GB | |
| Maximum Speed | 3200MHz | |
| Type | DDR4 | |
| Max Number of Channels | 2 | |
| Graphics Specifications | ||
| Processor Graphics | Intel UHD Graphics 750 | |
| Base Frequency | 0.40 GHz | |
| Max Dynamic Frequency | 1.35 GHz | |
| Max Video Memory | 16 GB | |
| Warranty Information | ||
| Manufacturing Warranty | 3 Years (No Warranty for Fan or Cooler) | |
Description
Intel 11th Gen Core i7-11700 Rocket Lake Processor
This Core i7-11700 Processor comes with Intel UHD Graphics 750. This new 11th gen Rocket Lake microarchitecture is manufactured with the 14nm process that comes with eight cores and 16 threads. These Processors also support 64-bit computing on Intel architecture requires an Intel x86-64 (64 bit) architecture-enabled BIOS. As this chip is updated to the latest BIOS revision, it nicely fits into any Intel 400 and 500 series motherboards. Focusing on this, all the major motherboard manufacturers have already started BIOS updates for their 400 and 500 series lineup.
Core Benefits of the Processor
Intel 11th Generation Core i7-11700 Processor having a base frequency of 2.50 GHz that can be reached as max turbo frequency at 4.90 GHz. The processor has a compatibility socket of LGA 1200 that is supported by 400 and 500 series Intel motherboards. It has a SmartCache of 16 MB containing 8 cores and 16 threads. With a bus speed of 8 GT/s, it has thermal design power (TDP) rating of 65W. This latest microchip has few expansion options such as 4.0 PCI express revision having configured up to 1×16, 2×8, 1×8+2×4, and a maximum of 16 lanes. Considering the memory this processor has a dual-channel of max 128GB of the size that supports up to DDR4-3200 bus speed.
